BETHLEHEM OFFERS A RANGE OF STEEL GRADES, COATING WEIGHTS AND SIZES TO MEET YOUR SPECIFIC
REQUIREMENTS. (continued)

THICKNESS
Tin Mill Products are available in various thicknesses and are produced to ASTM A623 tolerances unless otherwise agreed upon between the manufacturer and the purchaser.

Ordered
Thickness
Designation

Nominal
Thickness
50# .0055”
55# .0061”
60# .0066”
65# .0072”
70# 0077”
75# .0083”

Ordered
Thickness
Designation

Nominal
Thickness

80# .0088”
85# .0094”
90# .0099”
95# .0105”
100# .0110”
103# .0113”

Ordered
Thickness
Designation

Nominal
Thickness

107# .0118”
112# .0123”
118# .0130”
128# .0141”
135# .0149”

WIDTH/THICKNESS AVAILABILITY
SINGLE REDUCE ELECTROLYTIC TINPLATE
COILS AND CUT SIZE—MAXIMUM ORDERED WIDTH—INCHES*

Thickness Designation T1 T2 T3 T4CA T5CA
70 through 74 N/A N/A 34 N/A 34
75 through 79 N/A 34 35 35 36
80 through 89 34 34 36 36 36
90 through 94 34 35 36 37 37
95 through 135 35 35 36 37 37

SINGLE REDUCED ELECTROLYTIC CHROMIUM COATED STEEL
COILS AND CUT SIZES—MAXIMUM ORDERED WIDTHS—INCHES*

Thickness Designation T1 T2 T3 T4CA T5CA
70 through 74 N/A N/A 34 N/A 34
75 through 79 N/A 34 35 35 36
80 through 128 35 35 36 37 37

SINGLE REDUCED BLACK PLATE FULL-FINISH/CLEANED AND OILED
COILS AND CUT SIZES—MAXIMUM ORDERED WIDTHS—INCHES*

Thickness Designation T1 T2 T3 T4CA T5CA
70 through 74 N/A N/A 34 N/A 34
75 through 79 N/A 34 35 36 36
80 through 128 35 35 36 37 37

SINGLE REDUCED BLACK PLAT-DRY
COILS AND CUT SIZES—MAXIMUM ORDERED WIDTHS—INCHES *

Thickness Designation T1 T2 T3 T4CA T5CA
70 through 74 N/A N/A 34 N/A 34
75 through 79 N/A 34 35 36 37
80 through 128 36 36 36 37 37

* Notes: Minimum ordered widths for all items is 26 inches. Cut length sizes for all items are 18 inches minimum; 43 inches maximum.
